Doppler Ultrasound Equipment Hand held Doppler Machine 128 Elements 90~200mm Depth 235g Weight Wifi Connection

Doppler Ultrasound Equipment Hand held Doppler Machine 128 Elements 90~200mm Depth

235g Weight Wifi Connection

This set of infinite probes with integrated ultrasound circuit boards inside, can wireless connect to the iphone,

ipad that after installed ultrasound software, then realize the functions of a ultrasound scanner.

It is small and smart, convenient for carry and operation.

Specification

Item	1	2	3
Type	Linear	Convex	Linear
Frequency	7.5-10MHz	3.5-5MHz	7.5-10MHz
Depth	20-55mm	90-305mm	20-100mm
Elements	128	192	192
Radius	N/A	R60	N/A
Length	46mm	N/A	46mm
DR	N/A	40-100	40-100
FocusPos	N/A	0.1.2.3	0.1.2.3
Enh	0-4	0-4	0-4
Display mode	B, B/M, Color Doppler,PW, Power Dopper	B, B/M, Color Doppler,PW, Power Dopper	B, B/M, Color Doppler,PW, Power Dopper
APP interface adjustment	GN(gain) D(depth) ENH(enhancement) DR(dynamic range) F(frequency) Focus 8TGC Biopsy Page Left/Right Up/Down	GN(gain) 8TGC D(depth) ENH(enhancement) DR(dynamic range) F(frequency) PRF WF Focus Biopsy Page Left/Right Up/Down	GN(gain) 8TGC D(depth) ENH(enhancement) DR(dynamic range) F(frequency) PRF WF Focus Biopsy Page Left/Right Up/Down
Measurement	B: Length, Area/Circumference, Angle,Trace,Distance B+M: Heart Rate, Time, Distance B+PW: Velocity, Heart Rate (2), S/D, Depth	B: Length, Area/Circumference, Angle,Trace,Distance GA(CRL,BPD,GS,FL,HC,AC) EFW (BPD, FL) B+M: Heart Rate, Time, Distance B+PW: Velocity, Heart Rate (2), S/D, Depth	B: Length, Area/Circumference, Angle,Trace,Distance GA(CRL,BPD,GS,FL,HC,AC) EFW (BPD, FL) B+M: Heart Rate, Time, Distance B+PW: Velocity, Heart Rate (2), S/D, Depth
Dimensions	157(h)70(w)30(d)mm	157(h)70(w)30(d)mm	157(h)70(w)30(d)mm
Package size	240(h)235(w)100(d)mm	240(h)235(w)100(d)mm	240(h)235(w)100(d)mm
Net weight	221g	239g	223g
Gross weight	1.1kgs	1.1kgs	1.1kgs
Wifi type	802.11g/20MHz/2.4G	802.11g/20MHz/2.4G	802.11g/20MHz/2.4G
Working system	Android, iOS, Windows	Android, iOS, Windows	Android, iOS, Windows
Application	Breast Thyroid MSK Superficial Vascular Pediatrics Carotid Small Parts	Abdominal Emergency Cardiac Obstetrics / Gynecology Lung Kidney Urology	Thyriod Small Parts Pediatrics Vascular Carotid Breast MSK
Language	Chinese,English,Russian,Italian, Spanish,Portuguese(Brazil)	Chinese,English,Russian,Italian, Spanish,Portuguese(Brazil)	Chinese,English,Russian,Italian, Spanish,Portuguese(Brazil)
Battery life	5-8 years	5-8 years	5-8 years
Voltage	3.8v	3.8v	3.8v
Replaceable	Yes	Yes	Yes
Capacity	4200mAh	4200mAh	4200mAh
Standby	12h	12h	12h
Bootup	Platform dependent, generally <5 seconds	Platform dependent, generally <5 seconds	Platform dependent, generally <5 seconds

Standard Configuration

1	Wireless probe	1pc
2	USB cable	1pc
3	Power Plug	1pc
4	Wireless charger	1pc
5	Wrist strap	1pc
6	Portable aluminium alloy box	1pc
7	User's Manual_E format	1pc
8	Warranty Card_Eformat	1pc
