12" LED Monitor One Probe Connector Notebook Ultrasound Scanner With 9.7 Inch Touch Panel

Ask Lasest Price
Brand Name :	BIO
Certification :
Model Number :	3000K
Delivery Time :	7 working - days since getting full payment
Payment Terms :	Credit card, Paypal, T/T, Western Union, MoneyGram
Supply Ability :	100 units/month

Add to Cart

Product Details
Company Profile

12" LED Monitor One Probe Connector Notebook Ultrasound Scanner With 9.7 Inch Touch Panel

12" LED Monitor One Probe Connector Notebook Ultrasound Scanner With 9.7 Inch Touch Panel

Operation Video

Advanced Technology

Efficiency

High efficient work-flow design , allows the doctors complete the daily routine inspection quickly and easily , which greatly reduces workload.

Intelligent

Intelligent image optimization solutions can help you carry out diagnosis and assessment of the difficult patients with more confidence. It make your operation more accurate and efficient.

Visualization

Portable notebook design , full touch screen control panel makes machine interaction more convenient ,

and it allows doctors to master visual patient information anytime and anywhere

Technical Specification

Monitor	12-inch LED display
Control panel	9.7-inch touch screen
Probe connector	1
USB port	1
HDMI output	1
LAN output	1
TGC	8 segments
Gain	0~100 dB
Depth	1~23cm
Dynamic range adjustable	36~102dB
Edge enhancement	0~4
Dynamic range adjustable	36~102dB
Angle	50%~100%
Power	80%~100%
AQ Sonic	0~8
E Crystal	0~8
Lines Density	Low, medium, standard, high
Frame Average	0~7
Map	1~16
Focus position	1~4
Focus number	1~5
Brightness	±100%
Applications	Abdomen, Urology, Gynecology,Obstetrics ,Multinational Thyroid, Breast, Testes, Peripheral
Display mode	B, 2B, 4B mode M, B/M mode Zoom B mode Compound imaging Trapezoid imaging Multiple Beam Formation Lines Density: Low, Medium, Standard High
Zoom	Zoom frozen 9 Steps: ×0.5, ×0.75, ×1.0, ×1.5, ×2.0, ×2.5,×3.0, ×4.0, ×6.0
Memory	Cine-memory - Line Ratio B-mode (max.1024 frames) M-mode (max.1024 frames) Hard disk 32GB SSD
Weight	Gross weight:7.5kg (2 probes) 8.5kg (4 probes) Net weight :4.0kg,0.5kg(battery)
Power Requirements	Voltage: AC 100V to 240V±10% Frequency: 50HZ±1Hz; 60Hz±1Hz Rated Power: 250VA
Software & Accessories	Power Cable Operation Manual Hand-carry bag
Optional Accessories	Mobile Trolley Video Printer Ink-Jet Printer Laser Printer HDML Video Converter

Standard configurations	Optional
3000K main unit	6.5MHz transvaginal probe
12 inch high resolution color LED	7.5MHz linear probe
1 probe connector	5MHz micro-convex probe
1pc 3.5MHz R60 convex probe	6.5MHz rectal probe
1 USB port	6.5MHz rectal probe for vet
128 images of permanent storage	printer,Trolley

BIO- Catalogue for ultrasound scanner 3000K.pdf
